Vises for Small-Size Machines
VC-N series

• Just fit to small-size machines
• High rigid steel body
• Low-height body adopted, offering a wide machining area
• Aluminium jaws provided as standard
• Largest jaw opening
• Stable clamping force secured by the mechanical enhancement toggle mechanism
• Minimum lift up, offering the stable machining accuracy
• Parallel use as standard

Note 1: Please refer to the clamping force setting section of the instruction manual for the clamping range and setting method for each type.

Note 2: Please watch the video of the boosting mechanism. Click the image below to play the video.

Download Catalog here

Download instruction manual here

Model			VC103N	VC104N
Jaw Width (mm)			100	100
Jaw Height (mm)			40	40
Jaw Stroke (mm)			128	204
Work mounting Face Height (mm)			65	65
Total Height (mm)			105	105
Total Width (mm)			109	112
Total Length (mm)			355.5	431.5
Guide Block Width (mm)			14h7	14h7
Max. Clamping Force (kN)			20	20
Net Weight (kg)			16	19
Outline Drawing	2D	PDF
		DXF
		DWG
	3D	Parasolid
		STEP
