GNX36 (Blue coating carbide flat endmills for High Speed Machining and High Hardened Steel HRc 50~70, 4Flute) - YG1
E·FORCE
Flat endmills
• New shape and coating applicated for improved machinability and wear resistance • Suitable for machining high hardened steel HRc50 or higher and heat-treated steel series materials • 1mm or less double neck applicated for rigidity reinforcement achieve minimization of vibration • Blade rigidity reinforced by applying end teeth TOUCH
| EDP No. | 인선직경 | 날길이 | 온길이 | 생크직경 |
| D₁ | L₁ | L₂ | D₂ | |
| GNX36 005 | 0.5 | 1 | 40 | 4 |
| GNX36 006 | 0.6 | 1.2 | 40 | 4 |
| GNX36 007 | 0.7 | 1.4 | 40 | 4 |
| GNX36 008 | 0.8 | 1.6 | 40 | 4 |
| GNX36 009 | 0.9 | 1.8 | 40 | 4 |
| GNX36 010 01 | 1.0 | 1 | 40 | 6 |
| GNX36 010 02 | 2 | 40 | 6 | |
| GNX36 010 | 2.5 | 50 | 6 | |
| GNX36 010 03 | 3 | 50 | 6 | |
| GNX36 010 04 | 4 | 50 | 6 | |
| GNX36 010 06 | 6 | 50 | 6 | |
| GNX36 012 02 | 1.2 | 2 | 40 | 6 |
| GNX36 012 | 3 | 50 | 6 | |
| GNX36 012 04 | 4 | 50 | 6 | |
| GNX36 012 06 | 6 | 50 | 6 | |
| GNX36 015 015 | 1.5 | 1.5 | 40 | 6 |
| GNX36 015 03 | 3 | 40 | 6 | |
| GNX36 015 | 4 | 50 | 6 | |
| GNX36 015 06 | 6 | 50 | 6 | |
| GNX36 015 08 | 8 | 50 | 6 | |
| GNX36 015 10 | 10 | 50 | 6 | |
| GNX36 020 02 | 2.0 | 2 | 40 | 6 |
| GNX36 020 04 | 4 | 40 | 6 | |
| GNX36 020 | 6 | 50 | 6 | |
| GNX36 020 08 | 8 | 50 | 6 | |
| GNX36 020 10 | 10 | 50 | 6 | |
| GNX36 020 12 | 12 | 50 | 6 | |
| GNX36 025 025 | 2.5 | 2.5 | 40 | 6 |
| GNX36 025 05 | 5 | 40 | 6 | |
| GNX36 025 | 7 | 50 | 6 | |
| GNX36 025 10 | 10 | 50 | 6 | |
| GNX36 025 12 | 12 | 50 | 6 | |
| GNX36 030 03 | 3.0 | 3 | 40 | 6 |
| GNX36 030 06 | 6 | 40 | 6 | |
| GNX36 030 | 8 | 50 | 6 | |
| GNX36 030 10 | 10 | 50 | 6 | |
| GNX36 030 12 | 12 | 50 | 6 | |
| GNX36 030 14 | 14 | 50 | 6 |
| EDP No. | 인선직경 | 날길이 | 온길이 | 생크직경 |
| D₁ | L₁ | L₂ | D₂ | |
| GNX36 035 | 3.5 | 10 | 40 | 6 |
| GNX36 040 04 | 4.0 | 4 | 40 | 6 |
| GNX36 040 08 | 8 | 40 | 6 | |
| GNX36 040 | 10 | 40 | 6 | |
| GNX36 040 12 | 12 | 40 | 6 | |
| GNX36 040 14 | 14 | 40 | 6 | |
| GNX36 040 16 | 16 | 40 | 6 | |
| GNX36 045 | 4.5 | 14 | 50 | 6 |
| GNX36 050 05 | 5.0 | 5 | 50 | 6 |
| GNX36 050 10 | 10 | 50 | 6 | |
| GNX36 050 | 15 | 50 | 6 | |
| GNX36 050 20 | 20 | 40 | 6 | |
| GNX36 050 25 | 25 | 50 | 6 | |
| GNX36 055 | 5.5 | 15 | 50 | 6 |
| GNX36 060 06 | 6.0 | 6 | 50 | 6 |
| GNX36 060 12 | 12 | 40 | 6 | |
| GNX36 060 | 15 | 40 | 6 | |
| GNX36 060 20 | 20 | 50 | 6 | |
| GNX36 060 25 | 25 | 50 | 6 | |
| GNX36 065 | 6.5 | 18 | 50 | 6 |
| GNX36 070 | 7.0 | 20 | 50 | 6 |
| GNX36 080 16 | 8.0 | 16 | 40 | 6 |
| GNX36 080 | 20 | 40 | 6 | |
| GNX36 080 25 | 25 | 50 | 6 | |
| GNX36 080 30 | 30 | 50 | 6 | |
| GNX36 085 | 8.5 | 22 | 50 | 6 |
| GNX36 090 | 9.0 | 22 | 50 | 6 |
| GNX36 100 22 | 10.0 | 22 | 40 | 6 |
| GNX36 100 | 25 | 40 | 6 | |
| GNX36 100 30 | 30 | 50 | 6 | |
| GNX36 100 35 | 35 | 50 | 6 | |
| GNX36 110 | 11.0 | 30 | 50 | 6 |
| GNX36 120 26 | 12.0 | 26 | 40 | 6 |
| GNX36 120 | 30 | 40 | 6 | |
| GNX36 120 35 | 35 | 50 | 6 | |
| GNX36 120 40 | 40 | 50 | 6 |
| EDP No. | 인선직경 | 날길이 | 온길이 | 생크직경 |
| D₁ | L₁ | L₂ | D₂ | |
| GNX36 130 | 13.0 | 35 | 100 | 12 |
| GNX36 140 | 14.0 | 35 | 100 | 14 |
| GNX36 140 14S | 35 | 100 | 16 | |
| GNX36 160 | 16.0 | 32 | 100 | 16 |
| GNX36 160 32 | 40 | 100 | 16 | |
| GNX36 180 | 18.0 | 45 | 100 | 16 |
| GNX36 180 16S | 45 | 100 | 20 | |
| GNX36 200 | 20.0 | 45 | 100 | 20 |
| GNX36 250 | 25.0 | 50 | 120 | 25 |
